S Pro Series
· ALPD®5.0 RGBX® Full-Color Laser
· 4K+ (3,840x2,400) WUXGA (1,920x1,200)
· 120% Rec.709, 100% DCI-P3, 90% BT.2020
· 9 Optional Lenses, Throw Ratio 0.36~6.8:1
4K Professional Projectors with 20,000+ Lumens
The S Pro delivers 20,000 lumens of speckle-free, color-fringing-free performance — engineered to meet diverse professional requirements and give customers premium high-brightness projection solutions.
With optional 4K/WUXGA resolution, this product adapts to a wide range of scenarios, delivering crystal-clear images and revealing every detail with stunning precision.
This technology intelligently identifies and processes the highlights and shadows of displayed content. By expanding the dynamic range, it ensures bright areas are not overexposed and dark areas retain detail — resulting in more realistic, vibrant, and richly detailed images. With adaptive HDR and HDR10 support, it brings content to life with unparalleled clarity, detail, and realism for the ultimate visual experience.
Built-In Geometric Correction
Featuring keystone, curved-surface, and multi-point correction, this projector adapts to various projection angles and surfaces, making it suitable for a wide range of applications.
APCS (Appotronics Projectors Control System)
APOS (Appotronics On-screen Display)
Specification
| Model | AL-SK25KAP | AL-SU25KAP | |
| Display Technology | DLP™ chip×1, · DLP™ projection system | ||
| Panel Size | 0.8"DMD | ||
| Resolution | 3,840x2,400 | 1,920x1,200 | |
| Brightness① | 25,000lm/26,000lm (Center) | ||
| Light Source | ALPD® 5.0 RGBX® Full-Color Laser | ||
| Light Source Lifetime② |
20,000h |
||
| Contrast③ | Native Contrast: ≥1,600:1 Full On/full Off: ≥100,000:1 | ||
| Optional Lenses | 0.36:1; 0.53~0.63:1; 0.7~0.85:1; 0.85~1.1; 1.14~1.51:1;1.5~2.4:1; 1.69~2.42:1; 2.4~3.8:1; 3.8~6.8:1 | ||
| Blending | Horizontal and vertical edge blending | ||
| Screen Size | 100"~800" | ||
| Geometric Correction | Corner, keystone, curve, multi-point (up to 33x33 points) | ||
| Lens Shift④ | Vertical: ±50%, Horizontal: ±20%, Motorized | ||
| Signal Interfaces | Input Signal: HDMIx2 (4K/60P); DVI (1,920x1,200/60P); HDBaseET (1,920x1,200/60P); 3D SYNC Signal: 3D SYNC in; 3D SYNC out; IR 3D out Dynamic Contrast SYNC Signal: MULTI SYNC in, MULTI SYNC cbut |
||
| Control Interfaces | Ethernet Port: RJ45 Serial Port: RS232 Infrared Extension Cable Port: Remote IR in/out Debug Port: USB-B |
||
| Other Interfaces | USB Expansion Port: USB-A 12V External Power Supply Port: POWER 12V/1A |
||
| Power Supply | 100~240V AC 50/60Hz | ||
| Power Consumption |
Typical Power⑤ |
AC 100V~120V: 2000W⑥. AC 200V~240V: 2200W | |
| Standby Power⑦ |
0.5W | ||
| Installation | 360° Installation | ||
| Operation Noise⑧ | 47dB (Standard) | ||
| Dimensions⑨ | 625mm×533mm×178mm (LxWXH: 24.6"x 21"×7") | ||
| Weight⑩ | 35kg (77.2lbs) | ||
| Temperature⑪ | 0~40°C (32°F~104°F) | ||
| Storage Temperature | -10~+60°C (14°F~140°F) | ||
| Humidity | 10%~80% RH (No Condensation) | ||
|
① Comply with on ISO21118 standard.② Around this time, light output will have decreased by approximately 50%. Actual time may vary according to the operating modes, environment and other user behaviors.③ When DCI-P3 or BT2020 mode is selected, the brightness will decrease.④ Lens shift support:AL-XL070FR, AL-XL085FR, AL-XL110MA, AL-XL150MA, AI-XL169MA, AL-XL240LA,AL-XL380LA: Vertical +50%, Horizontal +20%.AL-XL053FR: Vertical +20%, Horizontal +8%. AL-XL036FR: TBD.⑤ Measuring conditions: Operating on the Standard modeel, ambient temperature 25°C,100~240V AC, 50/60 Hz.⑥ The maximum value of light output is limited to 20,000Im or less when using the projector with AC 100V to 120V.⑦ Measuring conditions: In the Power Settings menu, select Power Standby ECO option, then turn off the projector into standby mode.⑧ The test data was obtained at the ambient temperature of 25°C.⑨ Structural protrusions and lens not included.⑩ Lens not included.⑪ Light source brightness may decrease depending on ambient temperature. When projector is operating at high temperature or at high altitude, brightness will decrease correspondingly. Light output of projector will be reduced to 50% if ambient temperature exceeds 40°C (104°F) |
|||
